Small-batch freeze dryers are designed for pilot-scale process development, process validation, and low-volume production between laboratory freeze-drying systems and larger commercial production equipment. The FD-10S, FD-30S, and FD-50S models provide different condenser capacities and shelf areas for applications including pharmaceutical development, botanical extracts, material research, and specialty food processing.
The product range covers 10 kg, 30 kg, and 50 kg ice condenser capacities per 24 hours, with shelf areas from 0.12 to 1.50 m2 and shelf temperature ranges extending from approximately -50°C to +80°C, depending on model.
Product Range
|
Model Series |
Ice Condenser Capacity (24h) |
Shelf Area (m2) |
Shelf Temperature Range (°C) |
Ultimate Vacuum (Pa) |
Primary Application |
|
FD-10S |
10 kg |
0.12 to 0.20 |
-50 to +70 |
< 5 |
Laboratory R&D, Diagnostic Reagents |
|
FD-30S |
30 kg |
0.50 to 0.80 |
-55 to +75 |
< 3 |
Pilot Pharmaceutical, Botanical Extracts |
|
FD-50S |
50 kg |
1.00 to 1.50 |
-60 to +80 |
< 1 |
Small-Batch Production, API Lyophilization |
Technical Specifications
|
Specification |
Details |
|
Product Chamber |
316L stainless steel internal chamber; electropolished finish of Ra <= 0.4 um |
|
Shelf Construction |
Aluminum alloy shelves with internal fluid channels; shelf flatness <= 0.5 mm/m |
|
Ice Condenser |
Separate ice condenser chamber with pneumatic butterfly valve isolation and electric defrost |
|
Refrigeration System |
Multi-stage refrigeration configuration selected according to required shelf and condenser temperatures |
|
Vacuum System |
Rotary vane vacuum pump with isolation valve to reduce the risk of oil backflow |
|
Control System |
Siemens PLC and industrial touchscreen for recipe programming and process control |
|
Process Control |
Freezing, primary drying, and secondary drying process stages |
|
Data Functions |
Process data logging and data export according to the selected control configuration |
|
Power Supply |
380V, 50/60Hz, 3-phase |
|
Cooling Water |
15 to 25°C, where a cooling-water system is used for the condenser heat exchanger |
|
Compressed Air |
Required where pneumatic valves are included; exact pressure and consumption depend on configuration |
